Oli 74 Plus In Wall Electronic Cistern Converted Set

Oli74 Sanitariblock In-wall Concealed Cistern

The Oli 74 Sanitariblock In-Wall Cistern With Frame for wall hung toilet pans should be selected when installing a concealed cistern inside a solid wall or Drywall.

The metal frame that will be fixed to the floor will support the weight of the concealed cistern, toilet pan and the weight of the user.

Product Features

• Size: 58 x 115cm [Width x Height]
• Manufacturing code: 601821
• Contains one water inlet valve
• Resistance to atmospheric humidity (Hr <90%)
• Polypropylene (PP) cistern highly resistant and inalterable to thermal stress
• Equipped with Azor Plus Inlet Valve, with delayed refilling and silent (saves up to 9 litres of water per day)
• Supplied with anti-condensation lining
• Compatible with all floor and wall-hung toilet pans
• For solid or drywall wall installation
• Incorporates with 2 WC fixing bolts
• Tank is 18cm thick
• Height adjustable from 0 to 20cm
• Frame tested for a 400kg load

Oli Electra III Zamac Push Plate Chrome

The Oli Electra III Zamac* Chrome Push Plate is fitted with a state-of-the-art infrared sensor, this flush plate activates with just a wave of your hand, ensuring a touch-free operation for enhanced cleanliness.

Additionally, it offers a manual override for those times when physical interaction is preferred or when the sensor is not operational due to a power outage.

Product Features:

• Polished chrome Zamac* material
• Dual flush (60s full flush)
• Infrared sensor or mechanical actuation
• Compatible with Electronic Conversion Kit for in-wall cisterns
• Electric power connection (Oli 230/12v Switch Mode Power Supply Driver)
• Vandal resistant;
• 1.7cm thick
• Compatible with the OLI74 Plus cistern

* Zamac - ZAMAC is a family of alloys with a base metal of zinc and alloying elements of aluminium, magnesium and copper. Zamac alloys are part of the zinc aluminium alloy family.

Oli 230/12v Switch Mode Power Supply Driver

This transformation kit accessory is designed to power a ELECTRA III electronic flush plate, seamlessly integrating with OLI74 Plus concealed cistern. It offers the flexibility to connect up to four plates, ensuring a streamlined and efficient electronic drive system. Perfect for modernizing your facilities, this power supply driver is the key to a sophisticated and responsive restroom environment.

Product Features:

• Transformer 230/12V for ELECTRA Electronic Control Plates
• Possibility of connecting up to 4 plates

Oli Electronic Conversion Kit For Oli74 Plus

This innovative conversion kit effortlessly transforms your manually operated concealed cistern into a modern, electronically controlled unit compatible with the Oli 230/12V Switch Mode Power Supply Driver.
