Oli 74 Plus Sanitarblock 2 Inlet Valves Cistern With Frame

The Oli 74 Plus Concealed Cistern With Frame for wall hung toilet pans should be selected when installing a concealed cistern inside a solid wall or Drywall.

This Oli flushing cistern is distinguished by having two water inlet valves in its design:

• 01 - One for water direct from the mains
• 02 - Another for non-potable water designed for rainwater but applicable to other water sources as well such as boreholes water.

By reusing rainwater for toilet flushing, we can conserve clean drinking water, which is essential for human consumption. This approach promotes efficient water use and helps you save on your water bill.

The metal frame that will be fixed to the floor will support the weight of the concealed cistern, toilet pan and the weight of the user.

Product Features

• Size: 58 x 115cm [Width x Height]
• Manufacturing code: 601822
• Contains two water inlet valves for connecting two separate water sources
• Dual flush actuation 6/3L in-wall cistern (adjustable to 4.5/3L)
• Working pressure from 0,1 to 16 bar
• Resistance to atmospheric humidity (Hr <90%)
• Polypropylene (PP) cistern highly resistant and inalterable to thermal stress
• Equipped with Azor Plus Inlet Valve, with delayed refilling and silent (saves up to 9 litres of water per day)
• Supplied with anti-condensation lining
• Compatible with all floor and wall-hung toilet pans
• For solid or drywall wall installation
• Incorporates with 2 WC fixing bolts
• Tank is 18cm thick
• Height adjustable from 0 to 20cm
• Frame tested for a 400kg load
• Included:
  • Wall fixing kit
  • G ½’’ stop valve
  • Inlet and outlet toilet connection
  • Toilet fixing material (when applicable)
  • Outlet bend and Ø90/110 adaptor (when applicable)
